KEY FEATURE:
- Ultra Durable
- Main Japanese capacitors
- Enhanced thermal solution
- 120mm smart hydraulic bearing (HYB) fan
- OVP/OPP/SCP/UVP/OCP/OTP protection
- Support PCIe Gen 5.0 graphics card
- High-quality native 16-pin cable supports 600W output
- 80 PLUS Gold certified
- Fully modular design
- Compact design
- 10 years warranty (Adjusted according to different regions
Shipping cost is based on weight. Just add products to your cart and use the Shipping Calculator to see the shipping price.
We want you to be 100% satisfied with your purchase. Items can be returned or exchanged within 30 days of delivery.
| GroupName | Name | Value |
|---|---|---|
| Specifications | Cable Type | Flat, All black |
| Specifications | Connectors | ATX/MB 20+4 Pin x 1 : 610mm*1, CPU/EPS 4+4 Pin x 2 : 600mm+200mm*1, PCI-e 16 Pin x 1: 700mm*1, PCI-e 6+2 Pin x 4 : 600mm+150mm*2, SATA x 8 : 600mm+150mm+150mm+150mm*2, 4 Pin Peripheral x 3+4-Pin floppy x 1 : 500mm+120mm+120mm+150mm*1 |
| Specifications | Dimension | 150 x 140 x 86 mm |
| Specifications | Efficiency | 90% at typical load |
| Specifications | Fan Type | 120mm Hydraulic Bearing(HYB)fan |
| Specifications | Hold Up Time | >16ms |
| Specifications | Input Current | 15-6.5A |
| Specifications | Input Frequency | 60-50 Hz |
| Specifications | Input Voltage | 100-240 Vac (full range) |
| Specifications | MTBF | >100,000 hours |
| Specifications | Output Capacity | 1000W |
| Specifications | PFC | Active PFC (>0.9 typical) |
| Specifications | Power Good Signal | 100-150ms |
| Specifications | Product Type | 80 PLUS Gold Power Supply |
| Specifications | Protection | OVP/OPP/SCP/UVP/OCP/OTP |
| Specifications | Type | Intel Form Factor ATX 12V |
| Specifications | Warranty | 10 Years |
| Specifications | Weight |
